QYY- 1x4 Card Type Plc Splitter

Name： 1x4 Card Type Plc Splitter

Operation Wavelength(nm)： 1260～1650

Return Loss(dB)：≥55/50

Directivity(dB)：≥55

QYY- 1x4 Card Type Plc Splitter

Features：

. Good uniformity and low insertion loss

. Low Polarization Dependent Loss

. Excellent Environmental Stability

. Excellent Mechanical

. Stability Telcordia GR-1221 and GR-1209

. Advantage: Compact design, Easy to install in distribution box

Specifications:

Parameter	Unit	Specification (P Grade)
Operation Wavelength	nm	1260～1650
Channel Number		1X2	1x3	1X4	1x6	1X8	1x12	1X16	1x24	1X32	1X64	1x128
Insertion Loss(Max)	dB	4.3	6.2	7.2	9.8	10.5	12.5	13.6	16.５	17.2	21.0	25.5
Uniformity (Max.)	dB	0.5	0.6	0. 6	0.8	1.0	1.0	1.4	1.5	1.6	2.0	2.5
Polarization Dependent Loss	dB	0.2	0.3	0.3	0.3	0.3	0.3	0.3	0.3	0.3	0.5	0.8
Return Loss	dB	≥55
Directivity	dB	≥55

Parameter	Unit	Specification (P Grade)
Operation Wavelength	nm	1260～1650
Channel Number		2X2	2X4	2X8	2X16	2X32	2X64	2x128
Insertion Loss (Max.)	dB	4.5	7.5	11.2	14.6	17.5	21.5	25.8
Uniformity (Max.)	dB	0.8	1.0	1.2	1.5	1.8	2.5	3.0
Polarization Dependent Loss	dB	0.2	0.3	0.3	0.3	0.3	0.5	1.0
Return Loss	dB	≥55/50
Directivity	dB	≥55
