8 Cores Fiber Distribution Box

  • Model: QYY-FDB-8L
  • Material: ABS
  • Protection Level: IP 65
  • Product description:

The equipment is used as a termination point for the feeder cable to connect with drop cable in FTTx communication network system. The fiber splicing, splitting, and distribution can be done in this box, and meanwhile it provides solid protection and management for the FTTx network building.

1. Total enclosed structure.
2. Material: PC+ABS, wet-proof, water-proof, dust-proof, anti-aging, protection  level up to IP65.
3. Clamping for feeder cable and drop cable, fiber splicing, fixation, storage, distribution...etc all in one.
4. Cable, pigtails, and patch cords are running through their own paths without disturbing each other, micro type PLC splitter installation, easy maintenance.
5. Distribution panel can be flipped up, feeder cable can be placed by expression port, easy for maintenance and installation.
6. Box can be installed by the way of wall-mounted or poled-mounted, suitable for both indoor and outdoor use.

1. Environmental requirement
Working temperature: -40ºC~+85ºC
Relative humidity: ≤85% (+30ºC)
Atmospheric pressure: 70KPa~106Kpa
2. Main technical datasheet
Insertion loss: ≤0.3dB
UPC return loss: ≥50dB
APC return loss: ≥60dB
3. Thunder-proof technical datasheet
The insulation resistance between the grounding device and the metal parts of the box is no less than 2MΩ/500V (DC); IR≥2MΩ/500V.
The voltage resistance between the grounding device, and the box and its metal parts is no less than 3000V (DC)/min, no puncture, no flashover; U≥3000V


Product name Fiber Optic Distribution Box IP Rate IP65
Product Model QYY-FDB-8L Product Size 210*210*45 mm

2 inlet port φ15mm

8 out port φ6/12mm

Packing Quantity

20 pcs / carton

46*35*46cm 14.5kg

Compatible with

1:8 cassette splitter or

8 core adapter pigtail

Material ABS
Installation Type wall / pole-mounted Net weight 0.5kg
Accessories 1. Wall mounting kits : 4 pieces
2. Screws : 4 pieces
3. Cable tie: 4 pieces
4. Heat shrink protective sleeves: 8 pieces
5. Key :1 piece
